Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed

Brand Name : Anycut

Model Number : ZK1750

Certification : CE/FCC/RoHS

Place of Origin : Shenzhen

MOQ : 1 piece

Price : $742~1113/piece

Payment Terms : T/T,Western Union

Supply Ability : 1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/21 days

Delivery Time : 20~30 work days

Packaging Details : L2110mm*W400mm*H440mm

Max.cutting width : 1600mm

Control panel : 5.0 inch touch screen

Motor : Micro step subdivision motor

Cutting length : Unlimited

Max.cutting speed : 700mm/s

Max.force : 2000g

Auto contour cut : Camera

Main board : ARM smart fual-core chip

support software : CDR/AI/PS/Contour software/signmaster(optional)

connect or interface : USB cable/Udisk/WIFI(optional)

Contact Now

Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed



1. Powerful Cutting Force

- Equipped with a 2000g ultra-high pressure carriage, enabling precise XY-axis cutting and irregular full-cut operations.


2. Flexible Connectivity

- Features WIFI wireless connection (optional), along with USB cable and UDisk interfaces


5. High-Speed Performance

- Boasts a maximum cutting speed of 700mm/s.


6. Intelligent & User-Friendly Design

- Compatible with CDR, AI, PS, Contour, and Signmaster (optional).



Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed



Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed



Product Parameters

MODEL ZK1750
Max. media width 1750mm
Max. cutting width 1600mm
Packing size L 2110mm*W 400mm*H 440mm
Machine size L 2000mm*W 600mm*H 1100mm
Gross/Net weight 55kgs/49kgs
Control panel 5.0inch LCD touch screen
Motor Micro step subdivision motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 700mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 1
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows



Multi-functions

Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed



Anycut 1600mm Large Format High-precision High-pressure Stepper Motor Cutting Plotter with 700mm/s Speed
